AA8011/1100/3102 Aluminium coating Foil ,heat exchangers application

Brand Name : GBS

Model Number : GBS-QSB

Certification : ISO9001

Place of Origin : CHINA

MOQ : 5mts

Payment Terms : L/C, T/T, D/A, D/P

Supply Ability : 1800mts per month

Delivery Time : 25-35 works day

Packaging Details : wooden box

surface : golden, blue,white

appliaction : fins of cooling exchanger,air conditioners,etc

packing : wooden box or wooden pallets as per buyer's options

alloy : AA8011/1100/3102

Thickness : 0.085--0.35mm

Contact Now

HYDROPHLIC ALUMINIUM FOILS

Name	aluminum foil for finstock
Thickness	0.08~0.2mm
Color	golden,blue,black,silver,etc
Sleeve material	paper,steel
Width	200~1400mm
Core ID	75mm,150mm,200mm
Grade	1000,3000,8000 series
Temper	O, H22 , H24 , H26,H18
Surface quality	be free from Oil Stain, Dent, Inclusion, Scratches, Stain, Oxide Dicoloration, Breaks, Corrosion, Roll Marks, Dirt Streaks and other defect which will interfere with use.
Application	Air conditioner fin stock,condenser,evaporater,heat exchanger,radiator,refrigerators,building industry machinery
Quality	Chemical Composite and Mechanical Property are meted with GB/T Standard
Certificate	ISO9001:2008,ISO14001:2004,SGS and ROHS(if client request, paid by client), MTC(plant provided), Certificate of Origin(FORM A, FORM E, CO)

Alloy,Temper and Mechanical Properties in the room temperature
Alloy No.	Temper	Thickness(mm)	Tensile Strength(Mpa)	Elongation(δ%)	Cupping Value(mm)
8011	O	0.08~0.1	80~110	≥20	≥6.0
	O	0.1~0.2	80~110	≥20	≥6.5
	H22	0.08~0.1	100~130	≥18	≥5.5
	H22	0.1~0.2	100~130	≥20	≥6.0
	H24	0.08~0.1	120~145	≥15	≥5.0
	H24	0.1~0.2	120~145	≥18	≥5.5
	H26	0.08~0.1	130~160	≥8	≥4.0
	H26	0.1~0.2	130~160	≥10	≥4.5
	H18	0.08~0.2	≥160	≥1	---
3102	H26	0.08~0.1	125~160	≥8	≥4.0
3102	H26	0.1~0.2	125~160	≥10	≥4.5

REMARKS:
1) max. thinkness can be 0.35mm
2) Packing: wooden box or wooden pallets as per buyer's options
